Argonorth

ARGO 6 x 6 Frontier EFi

6x6 Frontier EFI Specs

Engine  3 year

Model  Kohler Command Pro

Horsepower (19 or 23) dependant on engine selection per SAE J1940

Displacement  694 or 747cc

Cooling  Air cooled

Starting  Electric

Brakes  Hydraulic

Steering  One-piece ergonomic handlebar steering control with mounted brake lever. For safety and ease of handling, the ARGO steering transmission provides continuous torque to all axles.

Controls  Right-hand twist grip throttle. Light switch and ignition switch.

Clutch  Belt-driven, Continuously Variable Transmission (CVT) maximizes engine power to the transmission.

Transmission  Planetary differential transmission with High and Low range; Forward, Neutral, Reverse.

Drive System  Roller chains drive machined sprockets that are spline-fit onto 1 1/4" diameter axles. Bearings are greaseable.

Frame  Formed steel channel construction, welded for high strength and durability. Polyester powder coated for lasting protection.

Body  Vacuum formed High Molecular Weight Polyethylene

Full Skid Plate  Optional

Load Capacity - On Land  700 lb. / 318 kg total

Load Capacity - Rear Compartment  140 lb. / 63 kg max.

Load Capacity - On Water  500 lb. / 227 kg total

Towing Capacity  1200 lb. / 544 kg

Seating Capacity  4 persons on land, 2 persons on water

Fuel Capacity  7.1 US Gallons (27 litres) See through polyethylene fuel tank. 8 hours of operation.

Speed (on land)  22 mph / 35 km per hour

Speed (on water)  3 mph / 5 km per hour

Shipping Weight  880 lb. / 399 kg

Axle Bearing Extensions  Front Optional - Rear Optional

Instrumentation  LCD Digital Gauge Cluster, Speedometer, Odometer, Voltmeter, Hour Meter, Tachometer, Low Oil Pressure and Parking Brake Reminder Lights, Check Engine Light

Tires  ARGO AT189 24 x 10.00-8NHS

Ground Pressure  1.7 psi (13.5 kPa) using tires, 0.67 psi (4.6 kPa) using tracks

Ground Clearance Tires  9.5 inches - 240 mm

Ground Clearance Tracks  10.5 inches - 265 mm

Operating Conditions  All weather,all-terrain,-40°C to +40°C
