Argonorth
8 x 8 750 HDi
Model Information
This 8-wheel drive amphibious off-road vehicle features an OHV V-Twin liquid cooled 748cc, 31 hp Kohler Aegis LH 775 electronic fuel-injected engine. The ARGO 8x8 750 HDi features effective throttle response, excellent fuel economy, reliable cold weather starting and outstanding high-altitude performance.
Features
Innovative triple differential ADMIRAL steering transmission provides even torque to all 8 of the big 25" ARGO tyres
Increased efficiency results in more power to the wheels for optimum performance.
Runs quiet and ensures a smooth ride
Large triple sealed bearing
Heavy duty front and rear axle hubs.
Self-adjusting hydraulic brakes.
New firewall and floor boards for increased leg room.
Independent emergency, parking brake.
Optional maintenance free AGM spill proof battery.
Easy access to the engine compartment.
Contoured dash design and premium padded bench seat.
Power to all wheels for optimal performance in challenging terrain .
One-piece ergonomic handlebar steering control.
State-of-the-art automatic continuous variable transmission with high and low range forward and reverse
Excellent approach and departure angles to easily overcome obstacles
Innovative design and space for up to 6 passengers
Low emissions which meet both EPA and CARB standards
Three-year limited engine warranty
Load capacity of up to 1150 lbs on land or 1000 lbs on water
Standard Equipment
LCD Digital Gauge Cluster (Speedometer, tachometer, odometer, voltmeter, engine coolant temperature, plus low oil pressure and parking brake reminder lights)
NEW 25" ARGO tires for optimum traction, smooth ride and better water performance
Hydraulic vented disk brakes for ease of operation
Independent emergency, parking brake
Full skid plate for lower body protection
Front & rear axle bearing extensions for increased axle and bearing life
Convenience Group (12 volt outlet, cup holders, grab handle)
Specifications
Engine 4 cycle OHV V-Twin gasoline engine, electronic ignition, full pressure lubrication and oil filter. 3 year warranty
Model Kohler Aegis LH775
Horsepower 31
Displacement 748 cc
Cooling Liquid Cooled
Starting Electric
Brakes Hydraulic
Steering One-piece ergonomic handlebar steering control with mounted brake lever. For safety and ease handling, the ARGO two mode steering for increased efficiency and increased agility.
Controls Right-hand twist grip throttle grip and dash-mounted choke control. Light switch and ignition switch.
Clutch and Transmission Belt-driven, Continuously Variable Transmission (CVT) maximizes engine power to the transmission. ADMIRAL triple differential steering transmission with dedicated Hi and Low selector; Forward, Neutral, Reverse
Drive System Roller chains drive machined sprockets that are spline-fit onto 1 1/4" diameter axles. Bearings are greasable.
Frame Formed steel channel construction, welded for high strength and durability. Polyester powder-coated for lasting protection.
Body Vacuum formed High Molecular Weight Polyethylene.
Full Skid Plate Standard
Load Capacity - On Land 1150 lbs / 521 kg
Load Capacity - On Water 1000 lbs / 454 kg
Towing Capacity 1800 lbs / 818 kg
Seating Capacity 6 persons on land / 4 on water
Fuel Capacity 7.1 Us gallons (27 litres) See-through polyethylene fuel tank. 8 hours of operation.
Speed - On Land 21 mph / 33.5 km per hour
Speed - On Water 3.5 mph / 5.6 per hour
Shipping Weight 1260 lbs / 571 kg
Axle Bearing Extensions Front - Standard...Rear - Standard
LCD Digital Guage Cluster Speedometer, Odometer, Voltmeter, Hourmeter, Tachometer, Engine Coolant Temperature, Low Oil Pressure, Parking Brake Reminder lights and Check Engine Light.
Tires ARGO AT189 25x12.00-9 NHS
Ground Pressure 2.1 psi (14.5 kPa) using tires 0.67 psi (4.6 kPa) using tracks
Operating Conditions All weather, all terrain, -40C to +40C
ARGO 8 x 8 (750 HDi)
