Model Information
The 8x8 Centaur is the ultimate all-terrain machine for those who require a durable, robust and dependable job site workhorse. Designed for comfort and safety, users can hit the ground running with little need to accessorize. The vehicle features a multitude of standard equipment, including ISO 5700 certified Roll Over Protection Structure, 3-point driver and passenger seat belts, integrated frame mounting locations and familiar steering and foot controls. With its 3” tubular steel frame and sealed axles, large payloads can be safely and reliably transported to most job sites. When the task takes you off the beaten path, 18” rubber or 22” snow tracks makes this an unstoppable partner on any job.

Features
Innovative dual-differential, hydrostatic steered Centaurmatic transmission

Turbo charged diesel engine provides superior high elevation performance

Modular accessory designs for quick and easy change-over

Long wheel base for increased ride comfort over rough terrain

Oil-bath drive axles supported by taper roller bearings

Standard Equipment
3-point driver and passenger seat belts

Full length skid plate for lower body protection

Digital Gauge Cluster (speedometer, tachometer, odometer, voltmeter, hour meter, engine coolant temperature, warning lights; low oil pressure, parking brake on and glow plug on)

3-point driver and passenger seat belts

Driver yoke with finger throttle

Specifications
Engine  DM 954 DT (Turbo Diesel) Briggs & Stratton Daihatsu. 2 year engine warranty

Type  Turbo diesel, in line 3 cylinder, 4 cycle, liquid cooled

Horsepower  34 hp @ governed 3800 rpm

Displacement  958 cc (58.46 cu in)

Torque  58 ft./lbs. @ 2400 rpm

Eléctrical  12 volt, 60 amp alternator, 960 CCA battery, dash mounted glow-plug-on and water in-fuel indicators

Brakes  Hydraulic disc brake with hand operated mechanical parking brake

Steering  Skid steered via SAUER DANFOSS 15 Series Transmission

Driver Controls  LCD Digital Gauge Cluster features Speedometer, Odometer, Voltometer, Hourmeter, Tachometer, Engine Coolant, Temperature, plus Low Oil Pressure, Parking Brake Reminder and Check Engine Lights, Water in fuel indicator and preheat timer. Steering wheel, dash mounted HI, LOW and REV gear selector with floor mounted accelerator and brake pedals

Clutch and Transmission  Continuously variable belt driven torque converter (CVT). Dual differential transmission, HI, LOW, NEUTRAL and REV

Final Drive System  RC80 roller chains from transmission to eight 1.5" (38 mm) diameter axles. Automatically adjusted tensioner for each drive chain. Tapered roller bearings in an oil bath support each axle. Standard semi-automatic or optional automatic chain lubrication system

Frame  Powder coated, 3" tubular steel, lower body support pan, welded construction. FEA analyzed for strength and durability

Body  Vacuum formed lower body and standard full skid plate formed from high molecular weight Polyethylene (HMWPE)

Load Capacity - On Land  2,000 lb. / 907 kg

Towing Capacity  2,200 lbs / 998 kg

Seating Capacity  Front bench seat for two persons

Fuel Capacity  12.6 U.S. gal./48 litres providing approx. 10 hours of operation

Speed - On Land  25 mph/40 km/h

Shipping Weight  2,400 lb. / 1,090 kg base model

Tires  HEAT AT190 25x12.00-9 NHS or high impact resistant 24" (610 mm) turf tires with reinforced rims (for track use only)

Vehicle Weight  2,720 lb. / 1,234 kg with Multi-Purpose Tracks - 2,920 lb. / 1,324 kg with Snow Tracks

Ground Pressure Tires  As low as 5 psi (34 kPa) with tires, 2.2 psi (15 kPa) with 15" (381 mm) tracks, 1.27 psi (8 kPa) with 18" (457 mm) tracks, 1.0 psi (6.8 kPa) with 22" (559 mm) snow tracks

Ground Pressure Multi Purpose Tracks  Zero Penetration 1.5 PSI/10 kPa Laden: 2.2 PSI/15 kPa 3" of Penetration 1.0 PSI/6.8 kPa Laden: 1.4 PSI/9.5 kPa

Ground Clearance  9"/229 mm at centre of vehicle

Operating Conditions  All weather, all terrain, -40F to +104F (-40C to +40C)



ARGO Centaur
